Description
1. Size:64.2mm*39.5mm*13mm
2. Output capacity:DC 5~30V, maximum current:20A, heat sink required if greater than 5A
3. Static current:20mA
4. Working current:50mA
5. Working voltage:DC 5-30V (commonly used universal working voltage 9V 12V 24V)
6. Signal voltage:DC DC4V~27V (commonly triggered by positive pole of power supply, or button, PNP sensor, PLC signal, etc.)
7. Service life:unlimited switching times
8. Working temperature:-40~85℃
6. The input and output adopt optocoupler isolation to enhance anti-interference ability and power consumption, ensuring stability. Industrial grade circuit boards, similar to PLCs, can set parameters that can be permanently memorized after power failure, and the signal terminal can maintain voltage signals for a long time
7. The delay time can be adjusted every 1 second from 0 to 999 seconds, 0.1 seconds from 0 to 99.9 seconds, and 1 minute from 0 to 999 minutes. Customers can freely switch the time range and size, and save the last set delay time when powered off without the need for repeated settings
Product Advantages:
1. Realize high-frequency fast and frequent on/off of the circuit
2. No noise will be generated during the on-off process
3. No electric sparks
4. There will be no electromagnetic interference
5. Longer service life than commonly used electromagnetic relays
Function Introduction:
1. The signal triggers the output to start working. When the time is up, it stops working. During the delay period, A: If it is triggered again, it becomes invalid. B: If it is triggered again, it will start timing again. C: If it is triggered again, it will stop resetting and terminate timing
2. The signal triggers the start timing time T1, and when the time reaches the output work T2, it is disconnected (reset). The time for T1 and T2 is adjustable
3. Recycling: Connect T1, disconnect T2, and cycle indefinitely. T1 and T2, both with adjustable time
4. When there is a signal, the output is working, keep working, the signal disappears, start timing, when the time is up, the output stops working. During the delay period, give the signal again, cancel the delay, the signal disappears, and start timing again
Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.
We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.
MOS Tube Control Module
SKU : YXS1303 Brand :
