Description

If you have ever tried to connect a 3.3V device to a 5V system, you know what a challenge. The bidirectional logic level converter is a small device that can safely reduce 5V signals to 3.3V and boost 3.3V to 5V at the same time. This level shifter is also suitable for 2.8V and 1.8V devices. The real difference between this logic level converter and our previous version is that you can successfully set the high and low voltages and safely raise and lower them on the same channel. Each level shifter has the ability to convert 4 pins on the high side to 4 pins on the low side, where two inputs and two outputs are provided for each side.

The level converter is very easy to use. The circuit board needs to be powered by the two voltage sources (high voltage and low voltage) used by the system. High voltage (eg 5V) to "HV" pin, low voltage (eg 3.3V) to "LV", grounding from system to "GND" pin
Compatible with 5-3V system
VIN connects to 5V system power supply
5A connect to 5V system
5B connects to 5V system
GND connected to 5V system GND
3V3 connect to 3V system power
3A connected to 3V system
3B connect 3V system
GND connected to 3V system GND
Size: 28×19mm / 1.1×0.74 inches
