Description

Product Overview:
The three-way step-down fan control board adopts a buck step-down scheme, with an input voltage ranging from 12V to 24V and an output current of up to 3A, which can better adapt to 4-wire and 3-wire fans on the market. By adjusting the dial potentiometer, the output voltage can be adjusted from OV to 13V, thereby adjusting the fan speed
Product Features:
1. Input voltage:12V~24V
2. Output voltage:0V~13V (suitable for 12V fans)
3. Maximum output current:3A
4. Red power indicator light, normal power connection, red indicator light on
5. Blue speed control indicator light, the higher the output voltage, the faster the fan speed, and the brighter the blue indicator light
6. Board size:49mm*39mm
7. Weight:16g
Instructions for Use:
Connect 12V~24V voltage through the DC power socket or wiring terminals (pay attention to positive and negative), adjust the dial potentiometer, and adjust the output voltage. The higher the voltage, the faster the fan speed, and the brighter the blue indicator light. Both 4-wire or 3-wire fans can be connected, pay attention to the direction of the interface

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

Three Channel Step-down Fan Control Board

SKU : YXS1649 Brand :

Price : $ 1.38

100 +: $1.38500 +: $1.381000 +: $1.38
