Description

Power supply voltage:dual DC power supply ±55-±80V
Rated output power:500W(±70V power supply 4 ohm load,distortion degree 1%)
Efficiency:>=90%
Signal to noise ratio:90dB
Frequency response range:20Hz-20KHz
Horn:4-8Ω
Amplifier board size:98*43*30mm(L*W*H)
Voltage amplification:50 times
Input sensitivity:1V(RMS)
Output short circuit protection:Yes
Over-temperature protection:Yes(the heat sink field effect tube temperature is higher than 100℃,shut down the output)
Total harmonic distortion:380W(±70 power supply 4 ohm speaker,distortion<0.1%)280W(±70 power supply 8 ohm speaker,distortion<0.1%)

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

IRS2092S 500W HIFI Digital Amplifier Board

SKU : YXC939 Brand :

Price : $ 4.08

100 +: $4.08500 +: $4.081000 +: $4.08

Quantity :

- +

ADD TO CART
