Description

SOC characteristic：

Built-in Tensilica L106 ultra-low power 32-bit microprocessor with 80MHz and 160MHz frequency support, RTOS support
Built-in TCP/IP protocol stack
Built-in 1 10 bit high precision ADC
Peripheral interface HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO
Deep sleep keeps current at 10uA and shutdown current is less than 5uA
Wake up, connect and pass packets within 2 ms
Standby power consumption is less than 1.0mW (DTIM3)
Built-in 1Mbyte SPI Flash

Wi-Ficharacteristic：

Support for 802.11 b/g/n/e/i
Support Station, SoftAP, SoftAP+STA mode
Support for Wi-Fi Direct (P2P)
Supports hardware acceleration of CCMP (CBC-MAC, counter mode), TKIP (MIC, RC4), WAPI (SMS4), WEP (RC4), CRC
P2P discovery, P2P GO mode/GC mode and P2P power management
WPA/PA2 PSK and WPS
802.11 i security features: pre-authentication and TSN
Support for 802.11n (2.4 GHz)
802.1h/RFC1042 frame packing
Seamless roaming support
Support AT remote upgrade and cloud OTA upgrade
Support for Smart Config (including Android and iOS devices)
range of working temperature:-40°C-125°C

Module size:26.8mm*16mm

Application scenario：
● Household appliances ● Home automation
● Smart sockets, smart lights ● Mesh network
● Baby monitor ● IP camera
● Sensor network ● Wearable electronics
● Security ID tag ● Wireless location awareness
● Wireless positioning system beacon ● Industrial wireless control

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment .

We can accept customized package to meet different requirements :
1.Every item will separately pack into plastic bag ,component, module can be packed in anti static bag .
2.Some fragile products such as the display screen can be packed in bubble bag .
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.
