Description

Board size:90*60mm
Board thickness:1.6mm
Board material:International standard board,pads all tin-plated,high-strength fireproof and drop-proof material,can be repeatedly disassembled.
The PCB board design is reasonable,and the commonly used chip components are used.
The left and right 3 columns of components are used to practice welding,and each column has a test point.
The middle circular circuit is a running lamp circuit,which is composed of CD4017,NE555 and light-emitting diode,which can work after welding without error.
The back of the circuit is also used,and there is a ruler,which is convenient for measuring the element.There are PCB wire examples for easy use in PCB design.
Circuit operating voltage:3~12V
Number of components:125pcs
Number of solder joints:274pcs
Solder length:35cm(diameter:0.6mm)
Sample welding time:35 minutes
