Description

Diameter:52mm
Handle length:25mm
Supply voltage:DC 6V

Introduction:
The circuit consists of a multi harmonic oscillator composed of a triode to drive two sets of LED alternating flashes. When connected to the rotating LED gyroscope, the vibration switch is powered on and the circuit operates. Due to visual persistence, patterns appear one after another

Circuit Principle:
When installing the battery, the vibration switch S1 is disconnected, so the circuit does not work. When rotating the gyroscope, due to centrifugal action, the vibration switch S1 is turned on, and the circuit works. The working principle of the multi harmonic oscillator circuit is that when the power is turned on, two transistors Q1 and Q2 must compete to conduct first. However, due to differences in components, only one transistor conducts first. Then the two transistors in the circuit take turns conducting and cutting off, and the two light-emitting diodes continuously cycle and emit light. When the gyroscope is rotated, a straight line will appear on the illuminated LED. Due to the staggered arrangement of the lights and the alternating lighting of each two lights, multiple dashed line shaped patterns will appear
