Description

Structural Characteristics:
1. Adopting Hongfa relay, stable and reliable performance
2. Compatible with two input modes: positive control and negative control
3. Each channel has an LED action indicator light for a more intuitive understanding of product performance
4. Each channel adopts optocoupler isolation to enhance anti-interference and isolation performance
5. Simultaneous power supply and independent control of the "IN" control terminal
6. The module adopts a standard "DIN" guide rail installation design, which is convenient, fast, and stable to install

Product Parameters:
1. Trigger signal:DC3.3V/5V/12/24V
2. Each triggering signal current:5mA
3. Power supply voltage:DC5V/12/24V
4. Current per circuit coil:18.8mA
5. Contact type:one normally open and one normally closed (single pole)
6. Maximum load current of each contact:10A
7. Action time:below 12ms
8. Reset time:less than 4ms
9. Maximum switching frequency:18000 times/hour
10. Mechanical life:over 20 million cycles
11. Relay installation:plug-in type (no)
12. Module installation method:DIN standard rail installation

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

Optocoupler SIolation Relay Module

SKU : YXS1320 Brand :

Price : $ 3.10~7.75

100 +: $3.10~7.75500 +: $3.10~7.751000 +: $3.10~7.75
