Description

Product Specifications:
Supply voltage:DC 4.5-55V
Average current:<60mA (5V power supply)
Peak current:150 mA (5V power supply)
Interface level:3.3V(compatible with 5V)
Measurement range: optional within the range of 0~10000ppm
Preheating time:3 minutes
Working temperature:0-50 ℃
Working humidity:0-95% RH (without condensation)
Weight:15g
Life:>5 years

Product Features:
The air chamber is treated with gold plating, which is waterproof and corrosion-resistant
High sensitivity, low power consumption
Excellent stability
Temperature compensation, excellent linear output
Provide output methods such as serial port (UART), analog (DAC), PWM waveform, etc
Long service life
Anti water vapor interference and non poisoning

Product Description:
The MH-Z14A carbon dioxide gas sensor is a universal intelligent small sensor that utilizes the principle of non dispersive infrared (NDIR) to detect the presence of CO2 in the air. It has good selectivity, oxygen free dependence, and long lifespan. Built in temperature compensation: With digital output, analog output, and PWM output, it is convenient to use. This sensor is a high-performance sensor that combines mature infrared absorption gas detection technology with precise optical path design and sophisticated circuit design

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

MH-Z14A NDIR Infrared Carbon Dioxide Sensor

SKU : YXC1647 Brand :

Price : $ 22.19

100 +: $22.19500 +: $22.191000 +: $22.19

Quantity :

- +

ADD TO CART
