Description

Product Introduction:
A learning infrared remote control switch allows the microcontroller to remember a key value data of the remote control, allowing it to control the switch of the relay. By learning again, the stored key data can be modified. For example, if you use the "8" button on the remote control for learning this time, you can use the "8" button to control the key after success, and the power loss data will not be lost. If you want to use the "9" button as the control, We need to relearn the microcontroller and make modifications accordingly

Instructions for Use:
1. Power on, correct wiring, LED indicator light on. After 5 seconds, the module operates normally and the relay operates simultaneously
2. Long press the S1 key, the indicator light flashes, and the module enters learning mode. Press any key on the remote control to stop the flashing indicator light. Learning is complete
3. The relay operating mode (self-locking or jogging) can be switched through the jumper cap

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

DC5V 1 Channel Infrared Remote Control Relay Module

SKU : YXS1419 Brand :

Price : $ 1.38

100 +: $1.38500 +: $1.381000 +: $1.38
