Description

8-band power resolution:10%,25%,40%,50%,60%,75%,90%,100%
Voltmeter accuracy:±3%
Work temperature:-10℃~65℃
Work humidity:10%~80%RH(no condensation)
Cut-out size:45*26*18mm
Click the switch to turn on and off the display,press and hold for 2 seconds to display the currently set battery type,and automatically resume after 2 seconds
Note:
The 1 string and 2 strings mentioned above refer to the nominal 3.6/3.7V lithium battery pack.Lithium iron battery 4 strings are universal with 12V lead acid,8 strings of lithium iron and 24V lead acid are universal,and so on
The minimum display voltage of the universal model within 30V is 6V and the highest,please be sure to note that it cannot be used for batteries above 24V! Because the load is prone to generate higher surge voltage,it is easy to burn the display.The minimum display voltage of the universal model within 100V is 7V,and the maximum peak withstand voltage is 200V

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

Voltage and Electricity Dual Display Meter

SKU : YXS1361 Brand :

Price : $ 1.62~1.74

100 +: $1.62~1.74500 +: $1.62~1.741000 +: $1.62~1.74
