Temperature Range-65 ~ +165°C (PE Cable -40 ~ +85°C)
Vibration MIL-STD-202,Method 213
The Characteristic Impedance of 50Ω
Frequency Range DC ~ 12.4GHz (Semi-Rigid Cable 0~18GHz)
Operating Voltage 335v Max (Effective Value)
Pressure Resistance 1000V RMS (Minimum Sea Level)
Contact Electronic Resistance
The Inner Conductor between ≤ 3 M Ω
Return Conductor between ≤ 2 MΩ
Insulating Electronic Resistance ≥ 5000 MΩ
Insertion Loss ≤ 0.15 DB/6GHz
Voltage Standing Wave Ratio Direct Flexible Cable ≤ 1.10 + 0.002f
Semi-Rigid Cable ≤ 1.05 + 0.001f
Curved Flexible Cable ≤ 1.20 + 0.003f
Semi-Rigid Cable ≤ 1.10 + 0.001f
Durability ≥ 500 Times (Cycles)
Shell Brass Plated Hard Gold
Pin Brass Plated Hard Gold
Wooden Bronze Plated Hard Gold
Elastic Contact Metal Plated with Shell Bronze
Insulator Polytetrafluoroethylene
Compression Joint Sleeve Copper Alloy Nickel Plated Or Gold Plated
O-Type Seal Silicon Rubber 6146

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment

We can accept customized package to meet different requirements :
1.Every item will separately pack into plastic bag ,component, module can be packed in anti static bag .
2.Some fragile products such as the display screen can be packed in bubble bag .
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.
