Description

Name:RE200B Human Pyroelectric Infrared Sensor
Sensitive element area:2.0×1.0mm²
Substrate thickness:0.5mm
Wavelength:7-14μm
Average transmittance of>75%
Output signal>2.5V
Noise<200mV
Balance<20%(working voltage)
Operating voltage:2.2-15V
Operating Current:8.5-24μA(VD=10V,Rs=47kΩ,25℃)
Source voltage:0.4-1.1V(VD=10V,Rs=47kΩ,25℃)
Working temperature:-20 ℃~+70 ℃
Storage temperature:-35 ℃~+80 ℃
Field of view:139°×126°

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

RE200B Human Pyroelectric Infrared Sensor

SKU : YXC592 Brand : JH Stock

Price : $ 0.25

100 +: $0.25500 +: $0.251000 +: $0.25
