Description

Microphone:6+1 MSM261S4030H0 to form an array
Lighting:12 LEDs are cascaded through double signal lines(adjustable color and brightness)
ports:10P FPC port and 2*5P 2. 54mm terminal port
Supply voltage:5V @800mA
Module size:78.1mm*88.8mm
Working temperature:-30℃~85℃
Sound pressure level:140dB SPL
Sensitivity: -26(dB,dBFS @1kHz 1Pa)
SNR:57dB(20kHz bandwidth,A-weighted)
Clock frequency:1.0-4.0MHz (normal mode),150-800kHz (low power mode)

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods

Microphone Array Module

SKU : 01S012 Brand : 01Studio

Price : $ 14.94

100 +: $14.94500 +: $14.941000 +: $14.94

Quantity :

- +

ADD TO CART
