Specifications:

Cable specification:4m㎡(AWG12)
Rated voltage:1000V
Rated current:30A
Contact Resistance:0.5mΩ
Contact resistance:≤0.2mmΩ
Compatible cable:2.5mm2 to 6mm2/AWG 14-12-10
Water proof class:IP67
Flame class:UL94-V0
Temperature range:-40~85℃
Safety Class:2
Withdrawal force: ≥50N
Insertion force:≤50N

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.
