Description

Quantity:100pcs/pack

Voltage:3.0-3.4V
Brightness:6000-7000mcd
Color temperature:6000-6500K(white),3000-3500K(warm white),9000-12000K(cool white and blue)
Leg length:17mm(long positive pole,short negative pole)
Reverse current:10μA
Viewing angle:120-140°
LED soldering conditions:
1.Soldering iron soldering:the tip temperature of the soldering iron(up to 30W)does not exceed 300℃,the soldering iron must be grounded,and the static electricity cannot exceed the range,the welding time does not exceed 3 seconds,the welding position is at least 3mm away from the fluid
Dip welding:the maximum temperature of dip welding is 260℃,the dip soldering time does not exceed 5 seconds,the dip soldering position is at least 3mm away from the fluid

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment.

We can accept customized package to meet different requirements:
1.Every item will separately pack into plastic bag,component,module can be packed in anti static bag.
2.Some fragile products such as the display screen can be packed in bubble bag.
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

5mm 100mW Straw Hat LED

SKU : YXC1374 Brand :

Price : $ 0.85~1.19

100 +: $0.85~1.19500 +: $0.85~1.191000 +: $0.85~1.19
