Description

The following 6 types of couplings have an outer diameter is 14mm and length is 22mm:
4-4 represents one side with a hole diameter of 4mm and the other side with a hole diameter of 4mm. (M4 machine screw for side hole)
5-5 represents 5mm hole diameter at one end and 5mm hole diameter at the other end. (M4 machine screw for side hole)
5-8 represents 5mm hole diameter on one side and 8mm hole diameter on the other end. (M4 machine screw for side hole)
6-6 represents one side aperture of 6mm and the other end aperture of 6mm. (M4 machine screw for side hole)
6-8 denotes one side aperture of 6mm and the other end aperture of 8mm; (M4 machine screw for side hole)
8-8 represents one side aperture of 8mm and the other end aperture of 8mm. (M4 machine screw for side hole)

The following three types of couplings have an outer diameter is16mm and length is 22mm:
6-10 represents one side aperture of 6mm and the other end aperture of 10mm. (M4 machine screw for side hole)
8-10 represents one side aperture of 8mm and the other end aperture of 10mm. (M4 machine screw for side hole)
10-10 represents one side aperture of 10mm and the other end aperture of 10mm. (M4 machine screw for side hole)

Package Type:
All goods will pack into cartons and wrapped full of waterproof tape before shipment .

We can accept customized package to meet different requirements :
1.Every item will separately pack into plastic bag ,component, module can be packed in anti static bag .
2.Some fragile products such as the display screen can be packed in bubble bag .
3.Some large machines can be packed in wooden cases.
4.We can label JH code or client's code on package so that customers can check easily after receive goods.

#45 Rigid Shaft Coupling

SKU : YXJ327 Brand : JH Sourcing

Price : $ 0.20~0.60

100 +: $0.20~0.60500 +: $0.20~0.601000 +: $0.20~0.60
